Most problems can be resolved by reviewing our General Operation Instructions.

Listed below are common questions and problems we receive over our Customer Service Hotline.  Just click on the question to find the solution to the problem you are having.  If you don't find the answer you are looking for, call the toll free number above for live technical help.

1. The machine is not spraying water.
2. The machine is not picking up any water.
3. There seems to be something missing from the machine.
4. I was cleaning my carpet and all of a sudden everything stopped.
5. The dark blue solution hose will not attach to the floor wand or upholstery tool.
6. The dark blue solution hose will not release from the floor wand or upholstery tool.
7. The recovery bucket overflows, but when I open the lid there is very little water in the bucket.
8. How do I purchase one of these fantastic machines?

The machine is not spraying water.

Please follow this checklist for a possible solution to your problem:

• Is there water in the open tank? (Tank "A")
• Is there power to the machine? (Check by turning on vacuum)
• Turn on pump and pull the trigger/lever on the stainless steel floor wand or upholstery tool.
• Insert a small pin into the spray nozzle located at the bottom (or floor end) of the floor wand, then try pulling the trigger/lever once again.
• If this does not solve the problem, call the Hotline at 1-800-882-4094

Back to Top

The machine is not picking up any water.

Please follow this checklist for a possible solution to your problem:

• Tip up the lid ( the part of the machine where the switches are located).  Is there a bucket that you can lift out?  If not, contact the store where you rented the equipment and obtain the missing bucket.
• Tip up the lid ( the part of the machine where the switches are located).  Wipe a rag across the screen on the vacuum motor.   (Click for illustration)
• Look at the blue and clear floor tool end that rubs on the carpet.  Make certain the slit in the blue part is down so it rubs on the carpet.  Rotate the floor tool end until it sits properly against the carpet.  (Click for illustration)
• Remove the light blue vacuum hose at the end connected to the bucket in the machine.  Place your hand on the gray pipe protruding from the bucket and turn on the vacuum.  Make sure the lid sits firmly on the bucket.  There should be suction against your hand.  Check the other end of the vacuum hose in the same manner.
• If this does not solve the problem, call the Hotline at 1-800-882-4094

Back to Top

There seems to something missing from the machine.

In order for the machine to work, you must have the following components:

• A coiled vacuum hose (Stored in Tank "A")
• A recovery bucket located under the lid (the part of the machine where the switches are located).
• A stainless steel floor tool or upholstery tool.
• If you are missing any of these items, contact the store where you rented the machine and obtain the missing component.

Back to Top



I was cleaning my carpet and all of a sudden everything stopped.

Please follow this checklist for a possible solution to your problem:

• Is the plug still securely in the outlet?
• Is there power to the outlet.  Use a lamp or other electric item to test the outlet.  Check your breaker or fuse box.
• Does the machine have a reset button?  If it is out and will not reset, the vacuum motor is hot and will take approximately 20 minutes to cool.
• If the problem still exists, call the toll free Hotline at 1-800-882-4094.

Back to Top



The dark blue solution hose will not attach to the floor wand or upholstery tool.

• Run your hand to the gold colored fitting at the end of the dark blue solution hose.  Find the part of this fitting that spins around.  Put your thumb and finger on it and slide it back towards yourself. (Click for illustration)
• If the fitting continues to be a problem, a couple drops of oil around the top will usually help.

Back to Top



The dark blue solution hose will not release from the floor wand or upholstery tool.

• Place floor tool or upholstery tool on the floor.  With one hand, push the dark blue solution hose towards the tool.  With the other hand, draw the fitting that turns around back toward the dark blue solution hose.
• If the fitting continues to be a problem, a couple drops of oil around the top will usually help.

Back to Top



The recovery bucket overflows, but when I open the lid there is very little water in the bucket.

• This problem is usually caused by excess suds or foam in the recovery tank.  Empty the recovery tank and add 4 capfuls of Defoamer before restarting.

Back to Top



General Operating Instructions

CAUTION:  DO NOT use boiling water, dyes, bleaches, powdered detergents or products other than nautavac brand in the machine.

PREPARATION

1. Vacuum the area to be cleaned with your household vacuum cleaner.

2. Lift the lid on the machine and wipe the vacuum screen before each use. (Click for illustration)

3. Pre-treat any heavily soiled areas with nautavac Prespotter.

4. Fill the solution tank (Tank "A") with hottest tap water available.  DO NOT USE BOILING WATER as damage to your carpet and to the machine may occur.  Always use a clean bucket or pail to fill the solution tank (Tank "A"), do not use the recovery bucket.

5. Add nautavac Stain Resistant Cleaner, Odor Control Cleaner or Upholstery Cleaner to the solution tank (Tank "A") at the rate described on the bottle.

6. Add nautavac Defoamer to the recovery tank at the rate described on the bottle.

7. Attach one end of the vacuum hose to the floor wand and the other end to the gray tube protruding from the recovery bucket.

8. Attach the dark blue solution hose to the floor wand. (Click for illustration)

9. Plug electrical cord into grounded wall outlet.

CLEANING

1. Turn on the vacuum switch and pump switch located on the lid.

2. Start by reaching out the floor wand a comfortable distance from your body, placing the floor tool perpendicular to the carpet. (Click for illustration)

3. Squeeze the trigger/lever and hold it down while you slowly and steadily pull the floor wand back toward you.  Go back over the same area until no more dirty water is seen through the floor tool end.  For faster drying time and more recovery of water, vacuum the same area without dispensing any cleaning solution.  Continue cleaning by slightly overlapping each previously cleaned area.  There is no need to apply heavy pressure to the floor wand, the machine does the work!

4. When the solution in Tank "A" becomes low, (it is best to prevent it from pumping completely empty), turn off both switches.  Disconnect the vacuum hose from the recovery bucket and lift the lid on the machine.  Remove the recovery bucket and discard the dirty water.  Replace the recovery bucket (remembering to add Defoamer) and reattach the vacuum hose.

5. Refill the solution tank (Tank "A") and continue cleaning.

CLEANUP

1. Turn off the pump and raise the wand overhead.  Press the trigger/lever until all the water drains from the white hose on the floor wand.

2. Remove the vacuum hose from the floor wand and vacuum any unused cleaning solution from the solution tank (Tank "A").

3. Turn off the vacuum switch.

4. Remove the vacuum hose from the gray tube protruding from the recovery tank.  Then lift the lid and remove the recovery bucket.  Discard the dirty water.

5. Wipe any hair and lint off the vacuum screen (Click for illustration) and any dirty water residue from the outside of the machine.

6. Coil the dark blue solution hose around the lid.

7. Coil the vacuum hose and place it in the solution tank (Tank "A").

8. You are now ready to return your machine.  Thank you for renting nautavac's Powerful Little Blue Machine.

Back to Top
